IP67 Rubber Wire Grommets
IP67 Rubber Wire Grommets, IP67 dustproof and waterproof protective wire replacement plug electrical cabinet wire and cable wire protection ring tapered rubber protective coil
বিবরণ
Tapered IP67 Rubber Grommets, wire grommets, cable grommets, rubber grommet sleeves
Model: PG7 PG9 PG11 PG16 PG21 PG29 PG36 M12 M16 M20 M25 M32 M40 M50
Waterproof grade: IP67 standard
Dust rating: IP67 standard product
Material: EPDM
Application: Electrically protect wire harnesses and cables passing through the panel, and provide IP67 waterproof protection, suitable for outdoor or wet conditions.
Product Specifications
| PART NO. | SIZE (mm) | HOLE (mm) | Model | PANNEL THICK (mm) | CABLE SIZE (mm) | ||
| D | L | H | |||||
| 02014008 | 20 | 13.3 | 6.8 | 12.7 | M12 | 0. 5-2. 0 | 3. 0-5. 0 |
| 02014002 | 21 | 18.5 | 5.8 | 16.5 | M16 | 1.0-4. 0 | 5. 0-9. 0 |
| 02014003 | 25.2 | 20.2 | 6.2 | 20.5 | M20 | 1. 0-4. 0 | 7. 0-13.0 |
| 02014004 | 30.5 | 22 | 5.6 | 25.5 | M25 | 1. 5-4. 0 | 10. 0-17. 0 |
| 02014005 | 38.6 | 24.6 | 6.8 | 32.5 | M32 | 1. 0-4. 0 | 14. 0-20. 0 |
| 02014006 | 47.5 | 29.8 | 8.1 | 40.5 | M40 | 1. 5-4. 0 | 19. 0-26. 0 |
| 02014007 | 58.8 | 35 | 9.9 | 50.5 | M50 | 1. 0-4. 0 | 26. 0-34. 0 |
| 02014001 | 20 | 16.8 | 5.6 | 12.5 | PG7 | 0. 5-2. 0 | 3. 5-5. 0 |
| 02014009 | 21 | 18.5 | 6.2 | 16 | PG9 | 1.0-4. 0 | 5. 0-7. 0 |
| 02014010 | 24 | 19 | 6 | 19 | PG11 | 1.0-4. 0 | 7. 0-10.0 |
| 02014011 | 28 | 22.2 | 6.1 | 23 | PG16 | 1. 0-4. 0 | 10. 0-14. 0 |
| 02014012 | 33.8 | 24.4 | 6.1 | 29 | PG21 | 1. 0-4.0 | 14. 0-20. 0 |
| 02014013 | 46 | 29 | 6.5 | 38 | PG29 | 1. 0-4.0 | 20. 0-24. 0 |
| 02014014 | 57.5 | 32 | 8 | 48 | PG36 | 1.0-4. 0 | 25. 0-32. 0 |
